Basic

• Code: NXT520BMX25-TS
• Rim Type: Clincher / Tubeless Ready
• Materials: Toray T700 Carbon Fiber
• Tubeless Compatible: Yes
• Warranty: 1 Years

Specification

• Size: 24"
• External Width: 25mm
• Rim Height: 48mm
• Weight: 750g+/-30g front / 895g+/-30 rear
• Valve Hole Diameter: 6.5mm / 8.5mm
• Spoke Holes Diameter: 4.5mm / 2.5mm
• Assembly Hole Diameter: 7.5mm / 8.0mm

Recommendation

• Spoke Tension: >300kg
• Torsion Strength : >50kg
• Ultimate Strength: >200kg
• Tire Size: 24''-520*1.0, 1 1/8

Appearance

• Weave: UD / 3K
• Finish: Matte / Glossy

Application

• application: Kid / Folding bike
