Introduction

For the first time we apply a new appearance design to the road bike carbon fiber rim —— Ripple 50V. When riding, especially at high speed, the wavy lines on the surface of this rim can disrupt the air flow around the rim, thereby reducing wind resistance and increasing speed. At the same time, this is also the first time we have applied the highest modulus carbon fiber material Toray T1100 to this bike rim, further reducing weight and improving rigidity and quality.

Basic

Code: NXT50RRV
Rim Type: Road Bike (Clincher, Tubeless Compatible)
Materials: Toray T700+T1100 Carbon Fiber
Edition: Supreme Edition
ASTM Classification: Condition 3
Warranty: 5 Years

Specification

Size: 700C
ERD (Effective Rim Diameter): 540mm
Drillings: 16 / 18 / 20 / 21 / 24 / 28 / 32
External Width: 30mm
Rim Height: 50mm
Weight: 360g
Valve Hole Diameter: 6.5mm (Presta)
Spoke Holes Diameter: 4.5mm
Assembly Hole Diameter: 7.5mm
Drain Holes: No (leave a note if you prefer Drain Holes)

Recommendation

Tire Size: 28 ~ 53mm Road / 28 ~ 40mm Cyclocross / 28 ~ 60mm Gravel
Tire Pressure: 30 ~ 90psi Road / 25 ~ 54psi Cyclocross / 27 ~ 79psi Gravel
Spoke Tension: 100 ~ 130kgf
Max System Weight: 144Kg

Appearance

Carbon Weave: UD
Finish: Free Coating / Matte / Glossy

Application

application: Road, Triathlon, Cyclocross, Dirt, Gravel, and Adventure riding.
