Basic

• Code: NXT32XU38 (Premium Edition)
• Rim Type: Clincher (Hookless)
• Materials: Carbon Fibers
• Tubeless Compatible: Yes
• Drillings: 28, 32, 36
• Warranty: 3 Years

Specification

• Size: 32"
• BSD (Bead Seated Diameter): 686mm
• ERD (Effective Rim Diameter): 644mm
• External Width: 38mm
• Internal Width: 30mm
• Rim Height: 30mm
• Weight: 530g
• Valve Hole Diameter: 6.5mm (Presta)
• Spoke Holes Diameter: 4.5mm
• Spoke Holes Angle: ± 6°
• Assembly Hole Diameter: 7.5mm

Recommendation

• Spoke Tension: 80~130kgf
• Tire Size: 2.0" ~ 2.75"
• Tire Pressure: 30 ~ 60psi
• Load Limit (One Wheel): 120kg

Appearance

• Carbon Weave Availability: UD / 3K / 12K
• Finish: Free Coating / Matte / Glossy

Application

• application: Trail / AM / Enduro / Freeride
