Introduction

NEXTIE offers a full line of custom bike carbon rims for mountain bicycle wheels, providing tailor-made solutions to meet your specifications. We have years of experience in wheel-building, and we cater to the needs of each customer. In our inventory, we offer different sizes carbon fiber mountain bicycle rims.

At NEXTIE, we build each wheel with precision and care, you can be confident that you are getting a high quality custom bicycle wheelset when you buy from us.

If you are interested in customzing your bike with new and stylish rims, the experts at NEXTIE are ready to make your bike look great and improve your preformance on the trails. We have been serving the cycling community since 2013, and all our custom bike rims are made here in China.

Wheelset Weight:

988g : DT180 hubs + Carbon Spokes Oval NXTCS05 + Alloy Nipples

1010g : DT180 hubs + Carbon Spokes Oval NXTCS02 + Alloy Nipples

1032g : DT180 hubs + Carbon Spokes Aero NXTCS03 + Alloy Nipples

1122g : DT180 hubs + Sapim CX Ray + Alloy Nipples

1028g : DT240 Hubs + Carbon Spokes Oval NXTCS05 + Alloy Nipples

1050g : DT240 Hubs + Carbon Spokes Oval NXTCS02 + Alloy Nipples

1072g : DT240 Hubs + Carbon Spokes Aero NXTCS03 + Alloy Nipples

1162g : DT240 hubs + Sapim CX Ray + Alloy Nipples

Carbon Mountain Rims

Alpha NXT29VM37U Carbon Rims, Vista Edition, 285g.

This rim could be used for XC (Cross Country), Marathon and Trail riding. The tire size for this model of rim is recommended at 1.95" ~ 2.75". The tire pressure is recommended at 30 ~ 60 psi.

Hubs

DT Swiss 180 / 240 EXP.

Spokes

Carbon Spoke NXTCS02 2.3g/pcs (270mm)

Carbon Spoke NXTCS03 2.6g/pcs (270mm)

Spokes Sapim CX-Ray 4.25g/pcs (260 mm)

Nipples

Sapim Polyax (Secure Lock, 14mm) Alloy in color black, red, orange, gold, blue, green, purple, pink, silver and more;

Tubeless Ready Wheels

Advantage 1 - Lighter: Since no tubeless tape wrapping on the Tubeless Ready wheels, the weight of Tubeless Ready wheel goes lighter than the weight of common wheel with tape wrapped;

Advantage 2 - Stronger: No holes drilling on rim bed (except valve holes) and the carbon fibers not being damaged, the rim bed would be kept integral and the strength increases;

Advantage 3 - Safe: Tubeless Ready wheels no risk of air leaking from the rim bed, the cycling stays safe and the journey could be longer than riding bike with common wheels.

Disadvantage: Needs professional maintaince in case of spoke breaking

Note: Tubeless Ready wheels could also be mounted with tubes.

What's in the Box

Carbon Wheelset (Front + Rear)

2 x Extra Spokes

2 x Tubeless Valve Stems

1 x Tubeless Tape

Documentation
